1.14 TRANSPORT
Machine transportation occurs by means of the four transport wheel
underneath the machine that
allow for easy movement.
To transport the machine proceed as follows:
1.
Move the handle to the vertical position (rest position);
2.
Move the slide switch (figure “1.10”) to the RT position (REST TRANSLATION);
3.
Lower the handle to either of the two sides, pushing the machine in the required direction.
TROLLEY FOR TRANSPORTATION
The trolley for transportation (figure “1.18”) is an optional accessory that makes the machine
easier to move about on irregular floors or going up/down steps.
Figure 1.18
