:Press Pro： the screen appears cuts memory
screen, enter the number.
:Press once, the flash cursor will move to the
previous cut. When in the Auto mode, if the
present cut it not out through, you can adjust the
knife depth, press the button once, backgauge
will move back to the last cut position, redo a cut
after make knife depth adjustment, you can
repeat its movement (this is limited to the cut
which is just used).
: Press once, the flash cursor will move to the next
cut position. If it displays ‘o’, the cursor won’t
be moved.
: Press , it will beep pi-pi-pi three times,
press the key again, it will beep 3 times again, it
will then confirm the entered cuts and store. The
flash cursor will back to Prog (if the is not
pressed twice, the program won’t be stored.)
In confirmation of all cuts are stored, the key is infected
with all cuts in a program. The cutter beeps when the key is
pressed for the first time, make sure all entered cuts are stored,
press the key once, the screen appears 0000.0 at this cut, and
all cut numbers in the back will be cleared.
: You have to confirm the start position of the cursor
before the key is pressed. Press , it will store
the desired cut positions in order.
How to use Division (÷) Program
Turn on the power to the cutter, press wait until the back
gauge moves back and recalibrates the position, the following
screen appears, you can operate the Mark VII.
Select an empty program number from 1-500 (say 3), press
and cuts memory screen appears.
Press and new screen appears:
~ 23
~ 24 ~
26.000
0 0
0.000
26.000
3 1
0.000
0.000
0.000
0.000
0.000
0.000
0.000
0.000
0.000
0.000
0.000
0.000
0.000
0.000
0.000
0.000
0.000
0.000
0.000
0.000
0.000
0.000
0.000
0.000
0.000
0.000
