1-46
12H-M12M0-0309-0
For DF-915
q Turn on the power while pressing both the start and stop keys to enter the maintenance mode.
“3. MAINTENANCE MODE” in CHAPTER 2 ELECTRICAL COMPONENTS
w Select “Code No.1: Folding plate 1 home position adjustment”, check the default adjustment value displayed
on the right 7-segment window and note it down.
e Press the clear key while pressing the stop key to initialize the folding stopper of folding plate 1.
r Press the test key to perform test folding.
t Measure the folded size of the second sheet ejected, and enter the adjustment value using the “+” or “–” key of
the speed key so that this folded size becomes the specified value.
Each time the “+” key is pressed, the folded size increases by 0.125 mm (0.005").
Each time the “–” key is pressed, the folded size decreases by 0.125 mm (0.005").
The settable adjustment values range from “–20” to “+20”. The folded size ranges from –2.5 to +2.5 mm
(–0.10" to +0.10").
y After setting, check the finish again by test folding.
u Repeat the above procedure until the folded size becomes the specified value.
(2) Adjusting folded size by folding plate 2
For DF-920
q Turn on the power while pressing both the start and stop keys to enter the maintenance mode.
SeeSee
w Select “Code No.2: STOP2 DEFAULT”, check
the default adjustment value displayed on the
LCD and note it down.
2.STOP2 DEFAULT
∗∗∗
Adjustment value
e The following procedure is the same as “(1) Adjusting folded size by folding plate 1”.
For DF-915
q Turn on the power while pressing both the start and stop keys to enter the maintenance mode.
w Select “Code No.2: Folding plate 2 home position adjustment”, check the default adjustment value displayed
on the right 7-segment window and note it down.
e The following procedure is the same as “(1) Adjusting folded size by folding plate 1”.
To Next Page
