Duplo DocuCutter CC-228 - Job and Batch Count Operation; Selecting a Job; Batch Count Function

Page 14
SELECTING A JOB
Actions Display Example
1 Turn on the power. Previous job will appear.
2
Press until the desire job is display.
01 → 02 → 03 → 04 … 12
3
Press to select job
4
Press to start operation.
BATCH COUNT FUNCTION
Batch count function is use to automatically stop the machine after a set count of paper has been fed.
Actions Display Example
1
Press until the desire batch count
number appears. The batch count will
increment by 10 every time the button is
pressed. Set “OFF” for no batch count.
OFF → 10 → 20 → 30 → 40 → 50
2
Press to select batch count.
3
Press to start operation.
# 1 L 50.8M19.0G00.0
(
N
)
count 23
# 4 L127.0M12.7G 6.3
(
N
)
count 23
# 4 L127.0M12.7G 6.3
(
N
)
count 23
# 4 L127.0M12.7G 6.3
(
N
)
count 23
# 4 L127.0M12.7G 6.3
(
N
)
batch
50
# 4 L127.0M12.7G 6.3
(
N
)
batch
50
# 4 L127.0M12.7G 6.3
(
N
)
count 23
