11. Error Message
Error Code
Symptom
Action
E001
Paper does not reach S3
1.1 Readjust side the guide
1.2 Check the media quality
1.3 Clean Sensor 3 if needed
1.4 Adjust the Level Sensor height
E002
1 Paper does not reach to S2
2 Undesired paper under S2 when
pressing the “START” key
1.1 Correct skew, readjust side guide
1.2 Check media not flat or curled
1.3 Sensor #2 dirty
1.4 Adjust the Level Sensor height
2. Remove the paper
E003
1. Undesired paper under S3
2. Sensor 3 detect InfraRed
1. Clear the paper out
2. Block the Infra Red source
E004
Feed Tray keeps going down
Level Sensor failed
E005
S3 seeing paper too long
Remove jamed paper in Standby Sensor
E006
Suction Fan no On/Off function
Suction Fan On/Off Index Sensor failed
E008
Sensor 8 keeps seeing Actuator/
1. Sure Feed Sensor Trigger malfunction
E009
Feed tray reach to upper or bottom
margin
Hold the Red button and press “Load” or “Start”
key to release the lock signal
E010
Stacker not Ready
Ld Er
Cover not closed or in place
Close the cover
db Er
Double feed.
1. Adjust the level sensor lower
2. Raise separator
tP Er
Feed tray up to suction head then
down without feeding
Sensor 4 Level Sensor too High
“- -“
Feed tray stop at bottom limit
Feed tray empty and reach to bottom mrgin
switch
“----“
Feed tray stop at the upper limit
Feeder tray reaches top margin switch
Error can not
reset
1. Standby sensor sensed the Infra
Red
2. Paper path has paper
1.Try to cover the sensor to block the Infra Red
2. Remove the sheet in paper path
No Power
E-stop is ON
Reset E-stop
