Duplo DPC-600PKG - Specification

- 5 -
Part I SF-300i Suction Feeder
1. Introduction
The SF-300i feeder is an automatic air suction, top-feed feeder that offers cost effective and
increase thruput of the DPC-600PKG flat bed cutter for Box-on-Demand.
2. Specification
Specifications
SF-300i Suction Feeder
Max. Paper Width
23”
Max. Paper Length
29.5”
Min. Paper Width
12”
Max. Thickness
0.14” (3.6mm)
Paper Weight
200gsm
Min Paper Size
17 x 11” (Long edge feed)
Power Requirement
110VAC, 50/60HZ 1.9A
Dimension
77.3” x 35.4” x 39.8” (1964 x 900 x 1012.6mm)
Weight
342 lbs (155Kgs)
3. Name Plate
