Duplo DPC-600PKG - Calibration Option

- 72 -
17.8 Offset
Items
Functions
X Offset
Calibration Ratio
Change this when the actual output size in the X direction is more or
less than designed.
Parameters. One unit is 0.01 time. The positive value is enlarged, the
negative value is reduced
Tool K3 Offset
X direction cutter K3 coincidence error correction
X-cursor Offset
X Direction Cursor Overlap Error Correction
Wheel K3 offset
X direction wheel K3 coincidence error correction
Deviation K3
Shaker
X direction shaker K3 coincidence error correction
Y Offset
Calibration Ratio
Change this when the actual output size in the Y direction is more or
less than designed.
Parameters. One unit is 0.01 times. The positive value is enlarged,
the negative value is reduced
Tool K3 Offset
Y direction cutter K3 coincidence error correction
Y- Cursor Offset
Y Direction Cursor Overlap Error Correction
Wheel K3 Offset
Y direction wheel K3 coincidence error correction
Deviation K3
Shaker
Y direction shaker K3 coincidence error correction
17.9 Calibration Option
If Design size is 400*400mm; Real cutting size is 401*399mm: adjust calibration X & Y value.
