Duplo DPC-600PKG - Specification

- 22 -
2. Specification
Max Sheet Size w/o CCD
L31.5” x W23.6”
Max sheet size with CCD
L31.5” x W23.6”
Min Sheet Size
L17” × W11” (Long edge feed)
Min Sheet Width
12”
Maximum Paper Weight
400gsm or 3.6mm Thickness from feeder, > 3.6mm manual feed
Minimum Paper Weight
200gsm
Productivity
15-45 secs per 12x18” depends on layout complexity
Repeat accuracy
±0.1mm
File format
PLT、DXF、XML
Data Interface
Ethernet
Registration System
CCD
Registration mark
Circle or dot with 5-10mm
Bar Code for File Retrieving
QR Code
Power Rating
220V±10%, 60HZ, 15A
Air Pump
1.5kW
Computer
Processor I5 7500 Series Dual Core or higher, Ram 4GB or more,
Hard Drive 5GB {SSD drives recommended for optimal
performance), Ethernet Port: 10/100Mb x1, PCI-E 1Gb Ethernet card
x1, Display: 19” LCD or bigger
Safety
CE/ETL
Roll to Sheet
Option
Machine Dimension - Net
L75.6” {2700mm} x W31.1” {1100mm} x H41.7” {1100mm}
Machine Dimension - Packing
L86.6” {3300mm} x W39.4” {1220mm} x H60.2” {1530mm}
Machine Weight - Net
926 lbs {420Kgs}
Machine Weight - Packing
1433 lbs {650Kgs}
