- 33 -
Step 3: Use 2mm Allen key to lose the 2-knife lock screws
①: Knife lock screw
②: 2mm Allen key
Step 4Insert the knife into the tool body, the knife edge should face the right side. The knife model and
the knife lock screws should face the front.
①: Knife edge
②: Knife mark and knife lock screw
