Appendix
EN-74
Audio
 High Definition Audio
 Two speakers, Sound pressure 85dB at 0.5M
 Average at 0.8, 1K, 1.2K, and 1.5KHz with
maximum volume Mic. Array
Camera
 Integrated 2.0Mega-pixel Web-cam with a Shutter
and Mic*2
 Support visual in-use White indicator
I/O Ports
 Two USB 3.1 Gen1 connectors
(One of USB3.0 has USB Power Share function)
 Two USB2.0 connectors
 One Audio combo jack (3.5mm)
 One RJ-45 jacks for internal 10/100/1000Mbit
Ethernet
 One VGA port
 One HDMI port (or optional Two Mini-DP ports)
 One D-sub 9-pin RS232 serial port (Optional to
support RS422/RS485 by customized BIOS)
 One DC-In jack
 One 41-pin Pogo Docking connector
 Optional 3 RF pass-thru connectors for Ext. antenna
of WWAN, GPS and WLAN
Communication
 Integrated Gigabit Ethernet with RJ45 connector
 Intel Dual Band Wireless AC 9260 (M2 socket type
2230)
 Supports 802.11a/b/g/n/AC, Bluetooth
®
v5.0
 Built-in dual antennas in display module
 M2 module (Type 3042) for optional WWAN EM7565
Module
 The SIM card is secured behind a security-screwed
door
 Built-in WWAN dual antennas in display module
(WWAN is a CTO option)
 Dedicated GPS module, UBLOX-NEO-M8N chip,
support GPS/GLONASS/BeiDou (GPS is a CTO
option, GPS Antenna supports GPS & GLONASS as
default, and Galileo or BeiDou support by request to
customize the GPS Antenna)
Security
 Kensington Lock Hole
 TPM 2.0 (compliant with FIPS 140-2)
 Optional Fingerprint scanner
Power
 AC Adapter Power Input: 100-240VAC, 50Hz-60Hz,
Output: 19VDC, 65W
 Optional Power Input: 100-240VAC, 50Hz-60Hz,
Output: 19VDC, 120W (120W AC Adapter is for
