8. Sewing
This description is based on the following assumptions:
–
The machine is a single-needle machine fitted with the following optional
equipment:
- FA Thread Trimmer
- RAP Electro-pneumatic seam-locking and sewing-foot lift, pedal-operated
- FLP Electro-pneumatic sewing-foot lift, pedal-operated
- HP Electro-pneumatic rapid stroke adjustment
–
The following functions are set at the operating panel:
- starting or finishing lock-stitch : ON
- sewing-foot position before and after cutting: DOWN
- needle position before cutting: DOWN (1st position)
- needle position after cutting: UP (turn-back after starting 2nd position)
–
Main switch on.
–
The last sewing process was completed with finishing lock-stitch and thread cutter.
Operating and function sequence
Sewing process Operation / Explanation
Prior to sew ing
Starting position
- Pedal in rest position
The machine is at a halt.
Needle up, sewing feet down.
Position material correctly
for starting the seam.
- Press key 2.
The needle is fully lowered.
- Push pedal half-way back.
The sewing feet are raised.
- Push material forward until it touches the needle.
Continued on next page !
26
123(4)
1234
