10.2 2nd stitch length STLS 13 - 2
The facility to activate a 2nd stitch length makes it possible to switch rapidly from
the assembly seam to the subsequent overstep seam.
The 1st or 2nd stitch length is selected with the keys on the sewing arm. The 2nd stitch
length is always smaller than the 1st.
The 2nd stitch length is active when the machine is switched on.
Function and operation
Name Function
1 Rotary knob Adjusts 1st stitch length
2 Scale 2nd stitch length is displayed
3 Knurled screw Adjusts 2nd stitch length
4 Scale 1st stitch length is displayed
34
1
2
3
4
