10.2.1 Integrated second stitch length
The subclasses 767-FAS-373-RAP-HP, 767-FAS-573-RAP-HP, 767-KFA-373-RAP-HP,
767-KFA-573-RAP-HP, 767-FAS-473-RAP-HP are equipped with a second stitch length.
Herewith it is possible to activate a shorter second stitch length just via a switch.
Both stitch lengths are defined by means of the two setting wheels 1 and 2.
–
Set the longer stitch length with the upper setting wheel.
–
Set the shorter stitch length with the lower setting wheel.
–
With the switch 4 you can change over from one stitch length to the other.
When the light emitting diode 3 is shining, the longer stitch length is active.
When the light emitting diode 3 does not shine, the shorter stitch length is active.
ATTENTION !
The stitch length adjusted at the lower setting wheel must
never be longer than that adjusted at the upper setting
wheel.
35
GB
1
2
3
4
