10.7 Seam center guide (only if 767-E74/... existing)
10.7.1 General
In order to operate the seam center guide the sewing drive DC1600/DA82GA is
required.
The seam center guide serves as guiding aid for topstitching operations. It guides the
center of two parallel seams to ensure an equal distance to the left and the right needle.
Support pressure of the stop guide for the seam center guide
ATTENTION !
The maximal pressure for the seam center guide should not
exceed 3 bar!
–
To set the support pressure pull out the turning handle of the pressure regulating
valve of the seam center guide and twist it.
Turning in clockwise direction= to increase the bearing pressure
Turning in c ounter-clockwise = to reduce the bearing pressure
N800 005611 0767 - E... on request
41
GB
