2. Setting up

IMPORTANT !

The special sewing machine may only be set up by trained

specialist personnel.

Packing must be removed prior to setting-up.

–

Remove safety bands and wood from upper part, table and frame.

–

Remove safety bands and block from motor.

2.1 Erecting the upper part

If the special sewing machine was not delivered fully assembled:

–

Screw hinges 2 and 3 to base plate.

Attach upper-part s upport 1.

–

Fit upper part.

–

Fit and tension V-belt (see section 2.3).

–

Fit belt guard and oil bath.

–

Align surge container 9.

The surge container must be turned so that it is vertical when the upper part of the

machine is vertical.

–

Place oil-recirculation felt 7 in the depression of the oil bath.

The hose 8 must not make contact with moving parts.

2.2 Transport

For internal transport the sewing machine must be lifted and moved by a suitable

vehicle (e.g. a fork-lift).

2.3 V-belt tension

After the machine has been moved the pre-set V-belt tension must be checked.

The tension in the V-belt 6 must be such that it can be depressed by about 10 mm by

applying finger pressure in the middle.

–

Loosen nuts 4 and 5.

–

Swivel drive until V-belt tension is c orrect.

–

Retighten nuts 4 and 5.
