DURKOPP ADLER HVP-20 Series - Part Name of the Control Box; Use the Following Numbers Cross Reference with the Control Box Picture

9
4. Part Name of the Control Box
(1). Use the following numbers cross reference with the control box picture :
1
： Mounting bracket for under table motor.
： Motor power socket
： Standing operation panel socket
： Motor encoder socket
： Safety switch socket
： Speed control unit
： Operation panel / box socket
： Motor encoder cable
： Motor power cable
： Motor body
： Belt guard
： External lamp socket
： Main power socket
： 7P synchronizer socket
： Presser foot signal output socket
： Sewing machine signal output socket
： Sewing machine signal output terminal panel
1
2
3
7
8
9
10
11
12
13
14
15
16
17
Be careful for all the connector shape and plugging direction. All connectors must be plugged and secured well.
4
5
6
