1. Safety Precaution
When install and operate HVP-20 MINI Servo Motor, precaution must be taken as the following.
This product is designed for the industrial sewing machines and must not be used for other purposes.
(1). Work environment :
(a). Power voltage:
Only use Power Voltage indicated on the name plate of the HVP-20 in ±10 % ranges.
(b). Electromagnetic pulse interference:
To avoid the abnormal running, please keep the product away from the high electromagnetic
machine or electro pulse generator.
(c). Temperature:
1. Please don’t operate in room temperature is above 45°C or under 5°C
2. Avoid operating in direct sun light or outdoors area.
3. Avoid operating near the heater.
4. Avoid operating in the area which humidity is 30% less and 95% more, also keeps away from
dew area.
(d). Atmosphere:
1. Avoid operating in dusty area, and keeps away from corrosive material.
2. Avoid operating in evaporative or combustible gas area.
(2). Safety in installation :
(a). Control box: Follow the instruction in this manual for proper installation.
(b). Accessories: Turn off the power and unplug the cord before mounting any accessories.
(c). Power cord:
1. Avoid power cord being applied by heavy objects or excessive force, or over bend.
2. Power cord must not set to be near the V-belt and the pulley, keep 3 cm space or above.
3. Check the outlet voltage before plugging the cord, make sure it match the voltage shown on
the name plate of the HVP-20 in ±10 % ranges.
Attention : If the control box is AC 220V system, please don’t connect to the AC 380V
power outlet, otherwise the error code will occur. If that happened,
please turn off the power switch immediately and check the power voltage.
Continue supply the 380V power over 5 minutes might damage the fuses
(F1,F2) of EMI board and burst the electrolytic capacitors (C4,C5) of power
board and even might endanger the person safety.
