98
Appendix2 Summaryofghteningtorques
1 2
4
3
5
6
7
9
q
8
Figure 34 - Summary of ghtening torques.
1 Bosch display holder on handlebars
2 Stem(2x)
3 Saddle
4 Seatpost
5 Spoke magnet speed sensor
6 Crank bolt
7 Thru-axle
8 Rearaxlenut
9 Dropout bolts
q Speed sensor
1 Nm
10-15 Nm
9-10 Nm
9-10 Nm
1 Nm
40 Nm
10 Nm
40 Nm
10 Nm
3 Nm
