dutch id PHANTOM - Adjusting the Brake Levers

79
EN
Figure 24 - Adjusng the quick release on the handlebars.
3. Close the quick release on the stem .
4
If you cannot close the quick release by hand, the quick release is too tight. Open the quick
release and turn the adjusting screw counterclockwise to loosen the quick release slightly.
4.8.3. Adjusngthebrakelevers
Iftheposionandangleofthehandlebarshavebeenadjustedcorrectlybutyoucannot
comfortablyreachthebrakelevers,youcanadjustthem:
1. Loosenoneofthescrewsonthegripslightlyunlthebrakelever17 can rotate around the
handlebars.
2. Turnthegripunlitisatananglethatallowsyoutoreachiteasily.
3. Tighten the screw on the handlebar clamp of the brake lever.
4
Optional:Toallowthebrakeleverstobeoperatedwithsmallerhands,youcanalsoreduce
the distance between the brake lever and the handgrip by turning the adjusting screw on the
brake levers clockwise.
6
CAUTION
Ҍ Oncethebrakelevershavebeenadjusted,itisimportanttocheckthatthebrakessllwork
correctly.Ifyoucansqueezetheleverallthewaytothehandgrip,thebrakeisnotght
enoughandthebrakewillnotworkopmally.
Ҍ Consult your dealer for the correct adjustment of the brake levers.
