78
Figure 22 - Adjusng the angle of the handlebars for a comfortable riding posture.
6. Use the markings on the handlebars to check that the handlebars are correctly aligned in the
centre.
Figure 23 - Checking the alignment of the handlebars.
7. Close the quick release on the stem . When closed, the quick release touches the stem and
the handlebars must not be able to move.
4
If the handlebars can still move, the quick release is not tight enough.
6
CAUTION
Ҍ Loosehandlebarscanmoveatunexpectedmomentsandleadtohazardoussituaonsor
accidents.Ensurethatthequickreleaseisalwaysghtenoughandthatthehandlebars
cannotmoveunexpectedly.
Youcanadjustthequickreleaseasfollows:
1. Depressthebuononthesideofthequickreleaseonthestemandopenthequickrelease.
2. Turntheadjusngscrewontheundersideofthequickreleaseclockwisetoghtenthequick
release.Useasize2.5hexwrenchforthis.
