Dux 21ENB5N - Specifications

Owner's Guide
31
Part: XXXXX Rev XX
Model 21ENB5N 21ENB5L 21ENB6N 21ENB6L 17ENB5N 17ENB5L 17ENB6N 17ENB6L
Approval certification number SAI-400195
Type
Installation Outdoor, Wall Mounted
Air Supply/Exhaust Power Flue
Operating Pressure 200 -1,000 kPa
Minimum Flow Rate 2.5 L/min
Dimensions 520mm (Height) x 350mm (Width) x 170mm (Depth)
Weight 15 kg 14 kg
Water Holding Capacity 0.5 L 0.5 L
Connection Sizes
Water Inlet R 3/4 (20mm)
Hot Water Outlet R 3/4 (20mm)
Gas Inlet R 3/4 (20mm)
Power Supply
Supply 230 - 240 VAC (50Hz)
Consumption
NG/LP : 36.0W/49.0W Freeze Prevention 129W NG/LP : 31.0W/41.0W Freeze Prevention 129W
Accessories Anchoring Screws
Specifications
Performance
Item Maximum Performance
Gas
Consumption
NG 159 MJ/hr 125.5 MJ/hr
LP 158 MJ/hr 130 MJ/hr
Maximum Hot Water
Capacity
25°C Rise 21 L/min 17 L/min
