Dyna-Glo DGO1890BDC-D - Grate Supports and Grates Installation

10
ASSEMBLY INSTRUCTIONS
10. Insert the cooking grate supports (F) into the
corresponding holes inside the smoker body (G),
starting from the bottom up.
NOTE: There are 12 possible positions to install
the cooking grate according to the need of
the user.
11. Slide the cooking grates (E) onto the grate
supports (F) inside the smoker body (G).
G
F
10
F
11
G
F
E
