12
ASSEMBLY INSTRUCTIONS
13. Remove the pre-assembled nut from the
temperature gauge (C) and insert the probe
through hole of the smoker door. Secure with nut
from inside panel. Tighten with wrench.
14. Slide the grease cup (I) into the grease cup
support located on the bottom of the
smoker body (G).
I
14
13
G
C
To Next Page
