11
11. Place the charcoal chamber (N) directly onto the
charcoal grate (M) and slide the grate onto the
support brackets located on the inside of the
smoker body (G). Slide the ash tray (L) under the
support brackets.
M
N
11
G
L
ASSEMBLY INSTRUCTIONS
12. Slide the four cooking grates (E) onto the
cooking grate supports (F) inside the
smoker body (G).
F
G
E
12
