GBK51948 RHINO2
Installation Manual Issue 5
case, the Release Brake function will be disabled and the state of the associated input pin
ignored until the power is cycled. Available on all input pins.
Charger Inhibit — Stops the scooter at the programmed Emergency Deceleration and
inhibits drive. If Latches is set to 'Yes', the scooter must be turned off and on before it is
possible to drive again. If Flashes is set to 'Yes', the Status Light will show a "Drive Inhibit"
flash code while the drive inhibit is active. See section 7.2 Flash Code Display for more
information on flash codes. Note: to make the Charger Inhibit pin compatible with the
industry standard where the inhibit signal must be connected to B- to activate inhibit, set
Active to 'Low'. Available on pin 14 and P/I.
Profile 2 — When this function is active, the scooter switches to Profile 2 (see 6.5.3 Drive
Performance). A typical application for Profile 2 is a user-selectable 'slow speed' mode that
can be used indoors, while Profile 1 is selected for outdoor use. Apart from changing the
maximum speed, the indoor profile can have its acceleration and deceleration adjusted as
well. Available on all input pins.
Slow — Limits the maximum speed of the scooter to the value that is set with Slows to. Has
no effect on scooter acceleration or deceleration. Slows to is a percentage of Maximum
Forward Speed or Maximum Reverse Speed. For example, if Maximum Forward Speed is set
to 80% and Slows to is set to 50%, the resulting maximum speed will be half of 80%, which
is 40%. If Slows to is set to 0%, the function behaves the same as the 'Stop' state of the
Slow/Stop function (including latching and flashing), which is described below. If Slows to is
set higher than 0%, the Slow function neither latches nor flashes. Available on all input
pins.
Slow/Stop — This function has three states:
l
Normal drive (pin not connected).
l
Slow (2.2kΩ connected to B+ if Active High or B- if Active Low).
Operates the same as the Slow function.
l
Stop (pin connected to B+ if Active High or B- if Active Low). Stops the scooter at the
programmed Emergency Deceleration and inhibits drive. If Latches is set to 'Yes', the
scooter must be turned off and on before it is possible to drive again. If Flashes is set
to 'Yes', the Status Light will show a "Drive Inhibit" flash code while the drive inhibit
is active. See section 7.2 Flash Code Display for more information on flash codes.
Only valid Active settings are 'High' and 'Low', all other settings disable the input (the
input will never become active). Available on all input pins.
Slow/Stop FWD — The same as Slow/Stop, but only applies to the forward direction;
reverse drive is not affected. If Latches is set to 'No' and forward Stop has been activated
and released, forward drive will still not be possible until the scooter has stopped and the
throttle has been returned to neutral. Flash codes are not used during this function (Flashes
is ignored). Available on all input pins.
Page 114 - Programming
