18 CA 251/301 M251EN2
EVERY 50 HOURS OF OPERATION (Weekly)
Levelling blade
- Lubrication
Fig. 26 Levelling blade
1. Lubricating nipples
Always lower the blade when the roller is
parked or is out of service.
1. Lower the blade.
2. Wipe the lubricating nipples clean on both sides of
the machine.
3. Lubricate each nipple (1) with four strokes of the
grease gun. Ensure that grease penetrates the
bearings. Use grease in accordance with the
lubricant specification on page 3.
1
WARNING
