Safety
6 4812325556EN 2017-11-22
Transport on steep ground
During the transport on steep ground (slope >5%), be careful
to not exceed the roller's maximum speed.
Selecting the low speed will increase the engine brake system
efficacy and also the life of the braking system.
Operation and transport on steep ground
Always drive the machine in slow speed when operating or
during transport on steep ground.
(>15%).
To drive or stop the machine, the rear wheels shall always be
towards the slope, that is, the roller shall go up normally and
shall go down in reverse.
Make sure there are no obstacles both in front or
behind your work area.
Driving near edges
When driving close to edges or holes, make sure that at least
¼ of the tires is on the compacted ground.
>15% (8,5°)
Fig.: Steep slope
Low speed (up to 4.7 mph or 7.5 km/h)
>5% (2,8°)
Fig.: Steep ground
v < max. speed. (9.3 mph or 15 km/h).
No mínimo 1/4
Fig.: Position of wheel when driving near
edges.
