Dynapac CP1200 - Machine Dimensions and Weights

Technical specifications
2017-11-22 4812325556EN 9
Technical specifications -Dimensions
Dimensions
Dimensions
mm
inches
A – Between axles
2760
108,6
B – Total width
2057
81
H1 – Total height
2576
101,4
H2 – Total height (Platform)
1875
73,8
K – Height from the ground
237
9,33
L – Total length
3650
143,7
A
L
H1
B
K
H2
