Dynapac CP1200 - Specifications and Torque

Specifications
56 4812325556EN 2017-11-22
Specifications
WEIGHTS
Operational weight with ROPS and
series equipment
5.106 kg
(11.256 lb)
Weight without ballast
4.706 kg
(10.374 lb)
Weight with ballast, wet sand
8.906 kg
(19.634 lb)
Weight with ballast
11.556 kg
(25.476 lb)
Weight with maximum ballast
12.000 kg
(26.520 lb)
FILLING VOLUMES
Hydraulic oil reservoir
70 L(18.49 gal.)
Hydraulic oil system
30 L(7.92 gal.)
Diesel engine lubricating oil
8,2 L(2.1 gal.)
Diesel engine coolant
17 L (4,49 gal.)
Fuel tank
215 L (56,79
gal.)
Water tank
410 L (108,3
gal.)
Sand ballast box volume (total)
2,24 m³
ELECTRICAL SYSTEM
Battery
1 x 12 V / 74 Ah
Alternator
12 V 120A
Fuses
Refer to "Fuses"
in the "Electrical
System" section”
COMPACTION DATA
Load on the tires:
- Without ballast
459 kg
- With wet sand ballast
991 kg
- With steel ballast.
1216 kg
- With the ballast at its max.
1333 kg
