Dynapac CP1200 - Page 28

Instrument/controls - Description and function
24 4812325556EN 2017-11-22
H1-AC Alarm
ERROR
CODE
DESIGNATION
FUNCTION
11
SAFE MODE: <9V or >36V LIMITED MODE: <18V or
>32V
SAFE/LIMITED Mode
13
Internal Reference Voltage
SAFE Mode
14
Analog Injection Channel
SAFE Mode
15
Watchdog (-)
SAFE Mode
16
Sensor Voltage Error
SAFE Mode
21
Pump Forward Control Valve Error/Feedback Error
LIMITED Mode
22
Pump Reverse Control Valve Error/Feedback Error
LIMITED Mode
25
Digital Outputs A1/A2
SAFE Mode
26
Digital Outputs B1/B2
SAFE Mode
28
Motor Control Valve Error/Feedback Error
LIMITED Mode
30
Motor Brake Pressure Defeat Valve/Feedback Error
LIMITED Mode
31
Pump/Engine Speed RPM
LIMITED Mode
35
FNR Error
SAFE Mode
39
Inch Sensor Error
LIMITED Mode
40
Inch Sensor not calibrated
Starting protection ON
43
Driving Sensor Error
LIMITED Mode
47
Mode Switch-B Error
LIMITED Mode
58
Motor RPM Error
LIMITED Mode
59
Motor Direction Error
LIMITED Mode
70
CAN Hardware Error
LIMITED Mode
72
CAN RX Message timeout
LIMITED Mode
98
CAN Shared Engine Control
SAFE Mode
LIMITED Mode
Limits the speed to 50%.
This mode is active as long as the fault remains.
SAFE Mode
The machine stops and cannot be used before the fault is
corrected.
