Removable steel ballasts
The CP1200 roller uses an innovative and patented system of
steel ballasts, which can be removed and installed easily and
quickly:
1. With the ballast box drained (without water and/or sand),
remove four side covers (1) from the ballast box.
2. Unscrew the nuts and counternuts (2) and four lower bolts
(3) of the bedplate in the steel ballasts. Remove the
bedplate (4) off the ballasts assembly.
3. Install or remove the ballasts, according to the necessity,
using the forks from a standard forklift. The ballasts grooves
(5) were projected so the forklift forks fit perfectly and to easy
their removal, installation and transport.
4. After installing or removing the ballasts in the box, mount the
bedplate, performing the reversal steps used to remove
them.
