Dynapac CP2700 - Machine Fault Lists and Operational Modes; Fail List and Operational Modes

Instrument/controls - Description and function
2018-02-19 4812325557EN 27
Fail list
Id
Byte . Bit
Description
Action
1
0.0
Hydraulic Filter
LED
2
0.1
Air Filter
LED
3
0.2
No Charging
LED
4
0.3
Low Fuel
LED
5
0.4
Low Spr. Water
LED
6
0.5
Engine Temp
LED
7
0.6
Hydraulic Temp (Temperatura hidráulica)
LED
8
1.0
Battery tension will be monitored.
< 9 V ou > 36V = SAFE MODE
< 18V ou > 32V = LIMITED MODE
Safe Mode
9
1.4
Sensor tension error. 5V.
<4,875V or >5,125V out of range of work
Safe Mode
10
3.1
Error in the hydraulic pump front valve
Error Feedback / Resistance Valve out of range.
Limited Mode
11
3.0
Error in reverse of the valve of hydraulic pump
Error Feedback / Resistance Valve out of range.
Limited Mode
12
3.2
Error in the Motor Control Valve
Error Feedback / Resistance Valve out of range.
Limited Mode
13
3.3
Hydraulic motor valve BPD.
Error Feedback
Limited Mode
14
2.3
Error in the rotation of the pump / diesel engine / Input
Frequency >10.000 Hz
Limited Mode
15
2.0
Short circuit on FNR
Safe Mode
16
2.1
Inch sensor error
Limited Mode
17
2.2
Throttle pedal sensor error
Limited Mode
18
2.6
Error in rotation motor H1/ Frequency >8.000 Hz
Limited Mode
19
1.1
Error in direction motor (sensor x joystick)
Limited Mode
20
1.2
Error in J1939
Limited Mode
21
4.0
Coolant Level
LED
22
4.1
Oil Pressure
LED
23
4.2
Water in Fuel
LED
LIMITED mode
Limits the speed to 50%.
This mode is active as long as the fault remains.
SAFE mode
The machine stops and cannot be used before the fault is
corrected.
