13
LT800 ILT800EN3
LT 800 (11") LT 800 (13")
A mm (inch) 810 (31.9) 810 (31.9)
B mm (inch) 330 (13.0) 330 (13.0)
C mm (inch) 1074 (42.3) 1074 (42.3)
D mm (inch) 422 (16.6) 422 (16.6)
E mm (inch) 280 (11.0) 330 (13.0)
Contact area,
m
2
(sq feet) 0,065 (0.70) 0,075 (0.81)
CONTACT
AREA
TECHNICAL DATA - DIMENSIONS
E
B
C
A
D
L000192B L000194B
