15
LT800 ILT800EN3
73
L000183B
1. Fill the fuel tank.
Tankvolume 3,0 lit. (3.2 qts)
Before start
Starting the engine
2. Check the engine oil level.
Oil volume 0,9 lit. (0.9 qts)
2
3. Set speed control lever to max. START position.
Min.
Max.
OK
Working mode
Start
Stop
6
5
4
4. Pull the starting cable out by the handle until you
feel a slight resistance. Let the cable run back; in
this way the entire length of the starting cable can
be used to start the engine.
5. Grip the handle with both hands.
6. Commence pulling the starting cable vigorously and
at an increasing speed (do not jerk it violently) until
the engine starts.
If after several attempts of starting the exhaust
begins to emit white smoke, move the speed
control lever to the stop position and pull the
starting cable out slowly 5 times. Repeat the
starting procedure.
7. After the engine starts, set the speed lever to the
idle position and warm it up without load for a few
minutes.
L000077A
L000195A
OPERATION
1
L000190B
