Dynascan DS55LX3 User Manual

DS55LX3 User Manual 21
Navigating the On Screen Display (OSD) Menu
Press the MENU button on either the real panel control or remote control to display the OSD. Use the navigation
arrows to select and adjust menu items.
ITEM DEFAULT
DESCRIPTION
DISPLAY MODE LAN.
Change the orientation of the Menu. The Menu can be
displayed in either LANDSCAPE or PORTRAIT mode.
AUTO BRIGHTNESS OFF
Turn On / Off auto brightness adjustment.
Note: With AUTO BRIGHTNESS on, the display brightness
adjusts according to the ambient light. When ambient light is
bright, the screen will adjust to the set HIGH LEVEL
brightness value; when ambient light is dark, the screen will
adjust to the set LOW LEVEL brightness value. With AUTO
BRIGHTNESS off, screen brightness will remain at HIGH
LEVEL set brightness value.
HIGH LEVEL 99 Adjusts the highest brightness level. Range 0 – 99.
LOW LEVEL 50 Adjusts the lowest brightness level. Range 0 – 99.
COLOR TEMPERATURE 6500K
Color temperature select (5500K 6500K 9300K and USER
MODE).
R 99 Adjust the red light level. Range 0 – 99.
G 99 Adjust the green light level. Range 0 – 99.
B 99 Adjust the blue light level. Range 0 – 99.
CONTRAST 32 Adjust the contrast level. Range 0 – 99.
SCREEN SAVER OFF Turn on / off image burn-in protection.
INTERVAL 5 min Sets image burn-in protection interval.
CURRENT TIME 00：00
Set the clock.
Note: The internal clock will continue to function when the
power is turned off.
TIMER OFF Turn on / off automatic power schedule function.
POWER ON TIME 00：00 Set turn-on time.
POWER OFF TIME 00：00 Set turn-off time.
DAISY CHAIN SETTING Set video wall function.
NUMBER OF ROWS 1
Set number of rows in video wall.
Note: The maximum number of rows in a daisy chain is 6.
NUMBER OF COLUMNS 1
Set number of columns in video wall.
Note: The maximum number of columns in a daisy chain is 6.
ROW POSITION 1 Vertical position in video wall.
