Introduction-17
B4850
BATTERY
STATUS
SOC
LED1 LED2 LED3 LED4 ALM
RUN
Shutdown /
OFF OFF OFF OFF OFF
OFF
STANDBY
75%-100%
OFF Flashing
50%-75%
OFF OFF Flashing
25%-50%
OFF OFF OFF Flashing
5%-25%
OFF OFF OFF OFF Flashing
0%-5%
OFF OFF OFF Flashing Flashing
0% OFF OFF OFF OFF
Flashing
Charging
100%
OFF Flashing
75%-100%
Flashing OFF Flashing
50%-75%
Flashing OFF OFF Flashing
25%-50%
Flashing OFF OFF OFF Flashing
0%-25% Flashing OFF OFF OFF OFF Flashing
Discharging
75%-100%
OFF
50%-75% OFF OFF
25%-50% OFF OFF OFF
5%-25% OFF OFF OFF OFF
0%-5% OFF OFF OFF Flashing
0%
OFF OFF OFF OFF
Flashing
Tab.2.4-LEDstatusindicators
Note: AspecialALMlightashingstate:whenthecommunicationbetweenbatteries
islostorabnormal,allthelightsfromSOCtoRUNofthemasterbatterywillash
together.
=meansgreenlightalwayson
=meansredlightalwayson
Flashing:meansgreenorredlightashing
