Powerbox Pro series User Manual
17
3.2.2 Mounted on the wall
The following accessories need to be added when install the powerbox Pro on the wall.
Battery bottom bracket ×1 Expansion screw ×4
4
． Fixing the expansion bolt M6 into the
bottom of the hole on the wall.
5
． Use the M6 bolt to fixing the Support
bracket to the wall and control the
torque at 6NM.
6
． Carry the battery box to the
installation site, and place it about
15mm away from the wall surface,
fixing the Support bracket and the
upper part of the battery box with
M6 bolts.
