Outputs
Relay
Contact Type & Single pole double throw (SPDT), latching or non-latching acon
(selectable); 2A resisve at 120/240VAC.
Lifeme: >500,000 operaons at rated voltage/current.
Isolaon: Basic Isolaon from universal input and SSR outputs.
Linear DC
Accuracy: ±0.25% (mA @ 250 , V @ 2k ). Degrades linearly to ±0.5%
for increasing burden (to specicaon limits).
Resoluon: 8 bits in 250mS (10 bits in 1s typical, >10 bits in >1s typical).
Isolaon: Reinforced safety isolaon from inputs and other outputs.
OPERATING CONDITIONS (FOR INDOOR USE)
Ambient Temperature: 0°C to 55°C (Operang), –20°C to 80°C (Storage).
Relave Humidity: 20% to 95% non-condensing.
Altude: <2000m
Supply Voltage and 100 to 240VAC ±10%, 50/60Hz, 8.5VA (for mains powered versions), or
20 to 48VAC 50/60Hz 7.5VA or 22 to 65VDC 5W
(for low voltage versions).
ENVIRONMENTAL
Standards: CE
EMI: Complies with EN61326 (Suscepbility & Emissions).
Safety Complies with EN61010-3
Polluon Degree 2, Installaon Category II.
Front Panel Sealing: To IP66 (IP20 behind the panel).
PHYSICAL
Front Bezel Size: 96 x 48mm (1/8 Din Horizontal).
Depth Behind Panel: 100mm.
Weight: 0.21kg maximum.
MANUFACTURING SITE
Address: The Hyde Business Park, Brighton, BN2 4JU, United Kingdom
SYMBOL EXPLANATION
Rang:
Power:
Consideraons:
Cauon general danger to life
or limb
General informaon and
noces.
