Dyson DC 23 - Dyson Stowaway Operation Guide; Components and Controls Identification; Basic Maintenance and Clearing Procedures

Service manual
Fitting notes
09
08 Slide the cyclone inlet off the
upper chassis.*
09 Disconnect the two wires from the
switch.
10 Remove the switch actuator and
spring from the switch housing.*
*Not necessary if replacing the cable rewind only.
