Fitting notes

Service manual

23 Locate the cable into the cable

rewind housing.

24 Locate the cable guard onto the

detail on the rear of the upper

chassis.

25 Press the cable guard onto the

upper chassis.

Fit the screw on the underside.

Cable rewind replacement - ﬁtting

Table of Contents3
Electrical Safety Testing5
Electrical Overview6
Wiring Schematic Motorhead Variant7
Electrical Fault Diagnostic - Motorhead Variant8
Cable Rewind Replacement - Removal9
Cable Rewind Replacement - Fitting17
Motor Bucket Assembly Replacement - Removal25
Motor Bucket Assembly Replacement - Fitting30
Main Chassis Replacement - Dismantle35
Main Chassis Replacement - Assemble40
Sub-Assemblies - bin Assembly43
Sub-Assemblies - Power Wand Hose Assembly45
Sub-Assemblies - Power Floor Tool - Dismantle48
Sub-Assemblies - Power Floor Tool - Assemble59
Main Body66
Cyclone and bin Assemblies67
Wand and Hose Assemblies68
Power Floor Tool Assembly69

Other manuals for Dyson DC 23

User Manual24 pages

Manual9 pages

Questions and Answers:

Need help?

Do you have a question about the Dyson DC 23 and is the answer not in the manual?

Dyson DC 23 Specifications

General

Model	DC23
Power	12 Amps
Type	Upright
Cyclone Technology	Root Cyclone Technology
Filtration	HEPA filter
