E Instruments 1500 User Manual

135
K000000000EJ 023826A0 100714
Date: 04/04/14
Time: 10.15
Fuel: Natural gas
Altitude: 0 m
R.H. air: 50 %
O2 4.2 ٪
CO2 9.3 ٪
Ex. Air 1.25
T flue 190.2 °C
T air 15.4 °C
∆T 174.8 °C
Loss tot 8.7 ٪
Eff.
tot 91.4 ٪
ET 4.9 ٪
ηt 91.4 ٪
CO 148 ppm
NO 40 ppm
NOX/NO: 1.03
NOX 41 ppm
CO amb 0 ppm
Draft: 0.05 hPa
Smoke: 3 1 2
Aver. n°: 2
Example of Partial Ticket.
Example of Full analysis report.
COMPANY Ltd.
Park Road, 9
Tel.800-555-1234
Oper.: John Smith
Sign.: ______________
Test according to
UNI 10389-1
E4500-3
Serial: 999989
Memory: 01
Analysis: Average
Date: 04/04/14
Time: 10.30
Fuel: Natural gas
Altitude: 0 m
R.H. air: 50 %
MEASURED VALUES
T flue 191.1 °C
T air 15.4 °C
O2 4.2 ٪
CO 146 ppm
NO 40 ppm
CO amb 0 ppm
Draft: 0.05 hPa
CALCULATED VALUES
Ex. Air 1.25
CO2 9.3 ٪
Loss tot 8.7 ٪
Eff.
tot 91.4 ٪
ηc 4.9 ٪
ηt 103.4 ٪
∆T 174.7 ٪
NO X /NO: 1.03
NO X 41 ppm
Ref. O 2 : 0.0 ٪
CO 182 ppm
Ref. O 2 : 0.0 ٪
NO 50 ppm
Ref. O 2 : 0.0 ٪
NO X 51 ppm
Note:-------------------
------------------------
------------------------
------------------------
------------------------
------------------------
------------------------
