E-MU Xboard Control
E-MU Systems 58
Individual Zones Settings
For each zone, you can define the keyboard and velocity range, and enable or
disable Zone-specific settings. Each zone is listed horizontally, with each zone’s
parameters listed vertically.
Zone Enable/Disable
Enables or disables the Zone. When this button is highlighted the Zone is
Enabled. Not highlighted means the Zone is disabled.
Zone Channel
Sets the MIDI channel that each Zone’s keys, mod wheel, pitch wheel, and pedal
send data across. Enter a value between 1 and 16.
Low Note and High Note
Sets the lowest and highest notes for each Zone. Enter a value between 0 and 127.
The Low Note must be a value equal to or less than the value of the high note. The
high note must be a value equal to or greater than the value of the low note.
Low Velocity and High Velocity
Sets the lowest and highest velocities for each Zone. Enter a value between 1 and
127. The Low velocity must be a value equal to or less than the value of the high
note. The high velocity must be a value equal to or greater than the value of the
low note.
Semitone Transpose
Transposes the Zone in semitones.
Send Pitch Wheel on Zone Channel
Enables or disables the Pitch Wheel for each Zone. With this enabled, the pitch
wheel sends messages across the Zone’s assigned MIDI channel.
X Board.book Page 58 Wednesday, April 12, 2006 10:44 AM
