E-Z-GO MPT 800 Technician's Repair And Service Manual

ELECTRONIC SPEED CONTROL (48V)
Page F-34
Repair and Service Manual
Read all of Section B and this section before attempting any procedure. Pay particular attention to all Notes, Cautions and Warnings
Fig. 16 ITS Adjustment (Sheet 2 of 2)
Micro switch
activated
Plunger enters 'ITS'
Plunger fully
activated
Pedal brac
ket
rests on rear
of pedal frame
opening
3
4
SOLENOID ACTIVATED
PEDAL ALL THE WAY DOWN
Cam
With
pedal all the way down:
Plunger should be flush with
or extend beyond rear of 'ITS'
No Adjustment Here
1.0 ± 0.3 volts
2.7
± 0.5 volts
