EAE EE-6503V2 - Page 29

Installation, Operation and Parts Manual
EE-6503V2
29
Pos.
Code
Name
Specification
Qty
1
310101010
Straight connector
G1/4-G1/4
1
2
330405027
Steel tank
18L
1
3
310101026
Straight connector
G1/4-G1/4 L=120
1
4
615019005
Connector B
6501-A4-B16
1
5
201102002
Hex flange screw
M5*10
4
6
202109064
screw for oil tank fixing
M6*30
4
7
207103019
Composite washer
M14
3
8
330101006
Hydraulic block
YF-3
1
9
320201004
Motor (380V)
380V-2.2KW -3PH-50HZ-2P
1
320201005
Motor (400V)
400V-2.2KW-3PH-50HZ-2P
1
