Eagle 2000 Series - Page 36

- 36 -
6.1 Illustration
Base (continued)
Name
Part Number
Qty
1
Turntable
FG-01A-19
1
2
Idler Gear
FG-01A-18
2
3
Block Limit Switch
FG-12A-16
1
4
Ramp Bolt
1
5
Idler Wheel
FG-01A-20
24
6
Turntable Gear
FG-01A-13
1
7
Limit Switch
N1CA2
1
8
Chain
12A
1
9
Base Frame
n/a
1
10
Tension Screw
91292A217
1
11
Motor Gear
FG-01A-31
1
12
Motor Mount Plate
FG-01A-28
1
13
Main Motor
CV750-30S
1
14
Cover
FG-01A-27
1
15
Motor Fan Cover
1
16
Fan Motor Cover
1
17
Mast Pin
1
