Eagle 2000 Series - Page 41

- 41 -
6.4 Illustration
Carriage – Continued from previous page.
Name
Part Number
Qty
1
Motor Cover
FG-08T-20
1
2
Gear Box
NMRV40-10-YS6344
1
3
Carriage Top Plate
FG-08T-02
1
4
Film Lifter
FG-08T-00
1
5
Roll Holder
FG-03A-18
1
6
Core Holder Shaft
FG-03A-16
1
7
Core Holder Washer
FG-03A-21
1
8
Core Holder
FG-03A-19
1
9
Protection Plate/ Bottom Plate
FG-08T-16
1
10
Micro Switch
7779K22
2
11
Roller Bearing
5972K168
1
12
Large Carriage Gear
FG-03-14
1
13
Carriage Prestretch Chain
06B
1
14
Small Carriage Gear
FG-03-12
1
15
Film Roller Assembly
FG-08-07
1
16
Roller Door
FG-08-14
1
17
Extended Roller Assembly
FG-08-08
1
18
Right Connection Block
FG-08-20
1
19
Left Connection Block
FG-08-20
1
20
Film Tension Switch
FG-03-11
1
21
Main Roller
FG-03-02
1
22
Pin Release Bar Assembly
FG-08-17
1
23
Film Roller
FG-03-03
1
24
Carriage Door Bracket
FG-08-04
1
25
Photo Eye Switch
A3R-2MX
1
26
Photo Eye Bracket
FG-08-21
1
27
Spring Bolt
FG-08-18
2
28
Spring
FG-08-17
2
29
Shrink Ring
FG-03A-20
1
30
Rivet Bolt
M10
1
