1.2 Specifications - Eagle 2000EBT
ITEM
SPECIFICATION EAGLE 2000EBT
Power Supply
110VAC, 60Hz
Turntable Speed
(Standard 0-12 rpm) (Optional 0-20rpm)
1
Turntable Motor
1 HP 750W 1420 RPM 220V 1:30 Gearbox
Turntable Diameter
78.5
Turntable Diagonal
170"
Turntable Height
3.4”
Turntable Gear
1:5
Turntable Chain
12A-1 ISO
Carriage Up/Down
1/3 HP 1390 RPM 220V 1:60 Gearbox
Carriage Up/Down Chain
08B-1 ISO
Pre-Stretch Motor
1/3 HP 1390 RPM 220V 1:20 Gearbox
Pre-Stretch Gear Ratio
1:12
Pre-Stretch Chain
06B-1 ISO
Film Stretch
250% pre-stretch with adjustable load force
Film Lift
Photo-eye controlled to match pkg height
2
Film Width
20” (standard) or 30” (option)
Adjustable Internal Limit Switches
8” Top & Bottom Rails
Max Film Height
12”
Mast Height
126.5”
Max Turntable Weight Capacity
5,000lbs
Max Package Height (2” Overlap)
118”
Machine Dimensions
151” X 78.5” X 130”
Shipping Weight
2125lbs
Attachment
Ramp or Custom Heavy Duty
3
Noise
≤75 DB
Environment
Humidity ≤98% Temperature 32-104°F
1
Note: Black product requires custom photo-eye installation.
2
Factory ramp is for use with hand pallet jacks only. Maximum combined weight of jack and product must not
exceed 1,300lbs. Custom heavy-duty ramps are available for use with loads exceeding 1,300lbs. (See page 5 for
details)
3
Turntable maximum RPM can be increased to 20 RPM upon request.
