23. OPTIONAL PEDAL BREAK
Item Part No. Description Qty
S1 C-221-640000-A Rubber Cover 1
S2 B-001-060001-0 Nut M6 1
S3 B-040-061412-1 Washer 6*14*1.2 1
S4 B-014-100251-0 Outer Hex Bolt M10×25 1
S5 PX-800-020300-0 Brake Pedal 1
S6 C-221-400000-0 Hex Locking Board Spring 1
S7 PX-100-020400-0 Connecting Rod 1
S8 B-010-060301-0 Hexagon Socket Head Bolt M6*30 1
S9 B-040-061412-1 Washer 6*14*1.2 1
S10 B-004-060001-1 Nut M6 1
S11 PX-100-020200-0 Brake Lever 1
S12 B-001-120001-0 Self-Locking Nut M12 1
S13 P-000-002001-1 Brake Block 4
S14 B-004-060001-1 Nut M5 2
