Eagle FishStrike 2000 - Section 4: Sonar Options & Other Features; ASP (Advanced Signal Processing)

45
Full Sonar Chart display (left); Sonar Page in split zoom mode (right).
Split frequency sonar display (left) with digital data display(right).
Sonar Page showing full sonar chart mode.
Surface clutter
Structure
Bottom signal
Fish arches
In FasTrack, fish
arches show as
horizontal bars.
Depth scale
Digital data
overlay
(depth &
temperature)
Surface signal
Zoom bar
FasTrack
bar graph
