Vantage Series 2200
>2) Program
Programming for Level/Volume Applications
From the main screen press the MENU key, then the number 02 keys.
Enter Security ID (00000000 from the factory), press the ENTER key
and then the number 01 key. The screen to the left will be visible on
the display.
Press the number on the keypad that corresponds to the engineering
units desired. Use the UP or DOWN button to move the list up or
down.
The next screen shown to the left is for selecting the volume units if the
meter is to be setup to display volume. If None is selected, the next
screen will be the entry of the maximum level to be measured and the
sensor offset. See page 2-3 for picture defining Max Level and Offset.
If a volume unit is selected, the screen to the left will appear. This is to
select the number of decimal to the right to display the volume units.
The next screen gives the choices for the type of tank being monitored.
The linear is for vertical standing circular tanks of rectangular tanks.
The Data Points selection allows the user to input up to 32 level verses
volume special curve. When this is selected a data entry screen will
appear. The Horiz Circ selection is for horizontal circular tanks.
The next screen is to enter the maximum tank level and the volume for
the maximum level. The cursor will be under the first digit of the level
value. Use the number keys to enter the desired value. If you need to
enter a larger number than the one displayed, use the DOWN/Left
arrow key to move the cursor to the left. After the last digit is entered
or the Enter Key is pressed the next screen will appear.
The sensor # and the previously programmed level units will be
displayed. If two sensors are used, the screen will prompt for which
sensor to calibrate. Move the cursor to the desired location in Max
level by using the DOWN/LEFT arrow key. Enter the maximum range
that the unit is to be programmed. Use the UP/NEXT key to drop the
cursor to program the offset region. Enter the sensor offset value.
The next screen will allow the user to assign the 4-20mA output. The unit can be programmed to
have 4.00mADC at zero level and 20.00mADC at span level or 20.00mADC at zero level and
4.00mADC at span level. Press 1 on the keypad to toggle the desired assignment. Press the
ENTER key.
If two sensors are being used, reenter the Program menu and repeat the previous programming
procedure if second sensor is for level or go the next page if for flow.
3-2
Level Units
01)Inches
02)Feet
03)Meters
Sensor #1
Units- Inches
Max Level 50.00
Offset 12.00
Volume Units
01)None
02)GAL
03)MET3
Program/Cal.
01)Level/Vol
02)Flow
03)Totalizer
Display Format
01)#.
02)#.#
03)#.##
Choose Tank Type
01)Linear
02)Data Points
03)Horiz Circ
Enter Tank Maximum
Level and Volume
Lvl= 50.00 In
Vol= 7500 Gal
To Next Page
